Controls:

Level:  Controls the output level of the pedal.

Drive:  Adjusts the gain and distortion of the pedal.

Bass / Treble:  Passive two-band tone stack, voiced like a British amplifier.

Contour:  Active midrange filter, boost or scoop mids up to 18dB.

Bypass Switching:

Hot Pink features true bypass switching using a latching relay and a soft-touch bypass footswitch.  Power on while holding the footswitch to enable the bypass pop-stop function (2 blinks for on, 1 blink for off.)  Hot Pink remembers your settings when powered off.

Power Supply:

Hot Pink requires a DC power supply with a 2.1mm pin, center negative.  Hot Pink will operate on power supply voltages up to 18V for increased headroom, and does not use a battery.  Hot Pink should work fine on a multi-pedal "daisy chain" connector, but if you encounter excessive noise or hum try a separate power supply.  Hot Pink requires approx. 20mA.
